s not shown in any of the cuts. Fig.23 is a lo-foot mill, as constructed for pumping-purposes.Fig. 24 is a 14-foot geared mill, as constructed for powerpurposes. In this case the rudder is very small, andplaced in front of the wheel, and parallel to the main AMERICAN WINDMILLS. 95 shaft. Fig. 25… … Fig. 22. 4, turn-table sleeve: 5, turn-table sleeve clip; 6, mainshaft; 8, spider ; 9, crank wheel; 10, crank pin ; 11, slidehead; 14, front slide; 17, chilled clutch ring (2 pieces) ;20, clutch oil cup; 21, forked clutch bar; 24, weightlever; 27, weight; 28, truss posts; 30, truss rod;…
