The windmill as a prime mover (1885)
Wolff, Alfred R · New York, J. Wiley & sons · leaf 114
Fig. 23. 01. aa /7~^W^¥i … 98 THE WINDMILL AS A PRIME MOVER. 42, arms; 43, arm irons; 46, section fans; 47, sectioncentre-bar castings; 48, section inner-bar castings ; 49,section rods; 55, splice irons for wood rods; 56, woodpitman rods; 57, pump attachment; 59, arm weight; 60,hand lever. The Adams Windmill, constructed by…Windmills
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
