Fig. 173.—Three-phase induction motor with wound secondary. The resistance, R,connected across the slip rings may be internal or external. It is left in circuit until the motorhas come up to speed, when it is short-circuited. When external to the motor, it is sometimesused to regulate the speed,… … Ammeter Core/ Mo/cfen S. T.O/7 S/vJCch r-^=
