r 100-lamp constant-current transformer.For 60 per cent, load, connect A to 1, B to 6, 2 to 5, load between C and E, F and H.For 70 per cent, load, connect A to 1, B to 6, 2 to 5, load between C and E, F and G.For 80 per cent, load, connect A to 1, B to 6, 2 to 5, load between C and D, F and G.For… … P. oo iin 114=7- ■^^ o
