Fig. 229.—Two plates of the type shown in Fig. 228 connected in series. 146 WIRING DIAGRAMS OF ELECTRICAL APPARATUS … Fig. 230.—Connections of a two-arm dial rheostat resister. This rheostat is equippedwith two arms, one short and one long; the short one connects the line with the inner circle ofcontact buttons, while the long one is insulated from the short one and connects the outercircle with the intermediate…
