Wood pattern-making; the fundamental principles and elementary practice of the art (1906)

Purfield, Horace Traiton · Ypsilanti, Mich., The Scharf tag, label & box co. · leaf 105

An illustration from Wood pattern-making; the fundamental principles and elementary practice of the art, 1906, leaf 105 — s typical of avery large class of patterns, as all patterns would bemade Onc-piCCC if they could be conveniently molded inthat shape. Before commencing the actual work on thispattern, notice particularly the position of the moldersparting and then the direction of the required draft. Thefirst… … Fig. 50. to the exact thickness, three-fourths inch, then nailedtogether so their center lines will be at the required angle PI.ATE WORK AND IRREGUI.AR PARTING 91 of 105°. On one surface of these lay out the shapeaccurately as indicated by the drawing, allowing aboutone-sixteenth inch for draft…

Patternmaking
