Wood pattern-making; the fundamental principles and elementary practice of the art (1906)

Purfield, Horace Traiton · Ypsilanti, Mich., The Scharf tag, label & box co. · leaf 128

An illustration from Wood pattern-making; the fundamental principles and elementary practice of the art, 1906, leaf 128 — Fig. 59. Fig. 58. before being fastened in place. They may be formed intwo ways. One is to plane up strips of wood to thedesired shape, and then cut them off to the required 114 WOOD patte:rn making length. A better way is to make a box as illustrated byFig. 58, each block being cut to exact length…

Patternmaking
