Wood pattern-making; the fundamental principles and elementary practice of the art (1906)

Purfield, Horace Traiton · Ypsilanti, Mich., The Scharf tag, label & box co. · leaf 223

An illustration from Wood pattern-making; the fundamental principles and elementary practice of the art, 1906, leaf 223 — sel with the hand until it cuts a shaving of the desiredthickness. As a general thing, the cylinder should becut almost to size with the gouge, leaving only a shavingor two to be removed by the chisel. 208 WOOD PATTERN MAKING Pattern-makers do almost all this finishing with ascraper like E, of Fig.…

Patternmaking

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
