f the wood follows thecircle as near as may be. Therefore, in laying out thesegments the chords of the curves should be parallel tothe grain of the wood. In building patterns of this type,a number of short segments are sawn out and glued in 62 WOOD PATTERN MAKING courses, one over the other with… … Fig. 32. Examples of constructional joints of still anothertype of patterns, sometimes termed plate work, is repre-sented by Figs. 33 and 34. Fig. 33 shows a framecut from solid wood, 18 inches wide and 2 feet 6 incheslong, by 1 inch thick. It is clear that strength and per-manence of form is…
Patternmaking
