Woodwork for the grades for use in manual training classes (1912)
Selden, Frank Henry · Valley City, N.D., The Maudslay press · leaf 197
rings in similarposition. You maynotice a differencein the warping oftwo boards of thesame kind of woodif one is cut at rightangles to the ringsand the othernearly parallel withthem.If at one time you leave a wide board lying flat on thebench top or floor and next time standing on end, or… … Fig. 270—Measuring Length of Bottom WOODWORK FOR THE GRADES 195 LESSON 58 WHISK BROOM HOLDER The ease with which you make this will depend on howyou work the parts. By observing the sizes given in Fig. 272you will see that it may bemade from one piece 20inches long, 5 inches wideand 3/s inch thick.…
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
