Fig. 296—Ripping Box Apm t The bottom is the next part to be nailed. Its position islocated by measuring in from each edge and end. Calculate theposition of the brads and draw light pencil lines showing theirlocation. The lines parallel with the edge should be drawnwith the pencil end of the gauge… … Fig. 297— View of Back of Box will hinder the bottom slipping, place the bottom on the bench and adjust the body of the box upon it, (Fig. 293). Both can then be turned over and the brads driven home. Another meth-od is clampingthe bottom inplace by securingthe lower jaw of aclamp in the…
