52—Rolling Piece at Fnd of Line WOODWORK FOR THE GRADES 49 be necessary to roll the piece as shown in Fig. 52, in orderto avoid hitting the bench with the head of the gauge. Fig.53 shows this rolling from the opposite sde. Notice that theright arm is par-allel with thepiece. After youhave drawn… … LESSON 11 PLANING TO WIDTH Place the piece on which you have drawn gauge lines ontop of the bench against the stop. Do not drive it against thestop. Plane the second edge down to the gauge line, makingthe piece \y2 inches wide. Test this piece by using the try-square as shown in Fig. 42. If you…
