Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 113
first work on Fig. 143 is the same as on Fig. 116.Next, the end is laid out by locating the four points at the endand edges according to the drawing (Fig.144) and drawing knife lines to these points.To use the trysquare, hold it as shown inFig. 145, where the head at the bladetouches the piece. Do… … 16*
