Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 114
Fig. 144 Drawing of Bread Board «• WOODWORK FOR THE GRADES 111 … Fig. 145—Lining Corner trysquare in the ordinary manner or the gauge may be set andpencil lines drawn as shown in Fig. 146. This affords pointsat which lines maybe drawn on theback or under sur-face. Saw the cornersto near the knifelines, holding thepiece on the bench-hook as shown inFig. 147.…
