Fig. 147 Sawing Comer fered, follow the directions in Lesson 18. A common mistakein chamfering such pieces is to make the chamfers too large. They should be not morethan 4 inch. Be care-ful to use a well sharp-ened pencil point in ihegauge and then workexactly to the lines. Ifyou wish to have a… … 148 -Plar: WOODWORK FOR THE GRADES 113 LESSON 30 ROUNDING AN EDGE Fig. 149 is a view of a rounded edge. Such edges maybe used on boxes and many other articles as well as on thebreadboard. (Fig. 143.) To round the edge, after it has been squared, draw apencil line along the center with a gauge and a…
