Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 246
Fig. 330— 1 WOODWORK FOR THE GRADES 243 The square pans for the bottom may be made of copper orof cast iron as shown in Fig. 251. If of cast iron, a patternis made and the pan cast in the usual way. This stand may be modified by changing the sizes of thevarious pieces, or by using more or… … Fig. 331—Clamping Rails to Legs and the rails pass around them. The corners and rails may besecured by ornamental wrought nails, or held entirely withglue. This latter plan should be used if the stand is of hardwood, especially if mahogany. Study the designs Figs. 250 and 252 and then try to makea…
Woodwork
