itsedge instead of rest-ing upon the spur,for if it rests upon thespur it will be impos-sible for you to drawan even line in woodwhich has unevengrain. Fig. 51 shows how the beam is rolled to cause it torest upon its edge; it also shows how the spur slants instead ofbeing perpendicular to the… … Gauge Line 48 WOODWORK FOR THE GRADES
