Fig. 84—Testing Chamfer from line to line.Test it with the bladeof the try-square asshown in Fig. 84. Be careful not toplane beyond thelines; rather leaveabout half the widthof each line. After chamferingeach end, place thepiece as shown inFig. 85 and chamferthe edges. In working the edges, the… … Fig. 85— Chamfering Edge WOODWORK FOR THE GRADES 77
