Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 80
Fig. 85— Chamfering Edge WOODWORK FOR THE GRADES 77 … Fig. 86—Measuring Chamfer moved parallel with the edge. After both edges have beenfinished and tested as shown in Fig. 84, test all the chamfersby measuring,Fig. 86. Theyshould all beof the samewidth; if theyvary, see if youcan find themistake andcorrect it. Donot fail to makeall the cham-fers…
Woodwork
