Fig. 162. Miter Cut-Off Gage. … Fig. 163. Sawing Simple Miters. stock the end of which will rest against the pin. Forlong stock the rod is turned end for end and the stopwith thumbscrew made use of. Figs. 163 and 164 show cut-off gages set ready for cut-ting stock at miters, simple and compound. They giveranges from 30° to 135°,…
