Woodwork for secondary schools; a text-book for high schools and colleges, prevocational and elementary industrial schools (1916)
Griffith, Ira Samuel, 1874-1924 · Peoria, Ill., Manual Arts Press · leaf 304
Fig. 453. Three Kinds of Locks. is held against the inside of the door or drawer and theposition of the keyhole is marked. (2) This hole isbored. (3) The lock is screwed in place, and (4) theescutcheon fastened to the outer or front surface. If aface-plate is used, the door is closed, the position… … -Top Mould FHIEZE MOULO Plinth oflBase /Mould Fig. 454. Names of Parts of a Typical Piece of Furniture. surface shall be slightly lower than that of the wood.With a lock such as the box lock. Fig. 453, sufficient woodmust be removed from the mortise so that the bolt mayact properly before the plate…
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
