Woodwork joints; how they are set out, how made and where used; with four hundred and thirty illustrations and a complete index of eleven hundred references (1921)
Fairham, William · Philadelphia and London, J. B. Lippincott company · leaf 149
Fig. 320.—^Marking Dovetails with Marking Awl» 137 Joints in Woodwork H, Fig. 317. Pare away any little irregularities whichmay be left in the corners with an J-in. chisel, thus leavingall smooth and neat. Lay the piece of wood which is tohave the dovetail marked on it flat upon the bench, andtake… … Fig. 321.—Sawing the Dovetails. Saw Work.—Take a marking awl, or a knitting needlewhich hcLS had its end sharpened, and mark the lines ofthe dovetail in a similar manner to that shown at Fig. 320.Remove the piece A, Fig. 318, and the lower piece shownat Fig. 318 will clearly show the marks aa as…
Woodwork · Carpentry
