Woodwork joints; how they are set out, how made and where used; with four hundred and thirty illustrations and a complete index of eleven hundred references (1921)
Fairham, William · Philadelphia and London, J. B. Lippincott company · leaf 151
on the drawer fronts and the drawerbacks first, after which they mark the drawer sides withthe marking awl, as shown at Fig. 320, the dovetail pinson the drawer front being sawn as at Fig. 327. The dove-tailing of the drawer back is shown at Fig. 324. This isthe type known as through dovetailing,… … Dressing Table Chest of Drawers. 140 The Dovetail Joint Fig- 325. First stab down with the vertical chisel, whichmust make the cut about 5^2 i^- ^^ front of the gauge
Woodwork · Carpentry
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
