Woodwork joints; how they are set out, how made and where used; with four hundred and thirty illustrations and a complete index of eleven hundred references (1921)
Fairham, William · Philadelphia and London, J. B. Lippincott company · leaf 175
Fig. 368.—Scribing Joint. Fig. 369.—Scribing Joint onSkirting Board. tage over the mitred joint, shown at C, because if slightshrinkage takes place, the joint does not open to the sameextent. If mouldings have undercut members, it is, ofcourse, impossible to scribe them to fit each other. , l5^ Ma… … Fig. 370.—Counter Top Jointed Fig. 371.—Method of Button-with Dovetail Keys. ing with Angle Iron. sufficient length for the entire span of the counter. Theboards are first glue-jointed and the ends are secured withdovetail keys. (See also pages 169 and 170.)
Woodwork · Carpentry
