Woodwork joints; how they are set out, how made and where used; with four hundred and thirty illustrations and a complete index of eleven hundred references (1921)
Fairham, William · Philadelphia and London, J. B. Lippincott company · leaf 180
Fig. 383.—Dovetail Keying. Fig. 384. counter or any similar job, three pieces of deal and twofolding wedges are required. The deal pieces should beabout 18 ins. long by 2 ins. by i in., the wedges (of hard- … Fig. 385.—Useful Manual Training Exercise Joint. wood) about 12 ins. long, both out of a piece of 2} ins. byI in., cut as shown at Fig. 386. A 2-in. by f-in. mortiseis cut in the centre of each of the deal pieces. They arethen screwed to underside of counter, through circled 169 Joints in Woodwork…
Woodwork · Carpentry
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
