Woodwork joints; how they are set out, how made and where used; with four hundred and thirty illustrations and a complete index of eleven hundred references (1921)
Fairham, William · Philadelphia and London, J. B. Lippincott company · leaf 43
Fig. 83. Fig. 84. The Two Parts of the Joint Marked. The joint, when marked out, will appear as at Figs.83 and 84, and the portions which are to be cut away maybe shaded with a pencil as indicated; this will prevent … Fig. 85.—Boring previous to Chiselling. mistakes arising whilst cutting the work, especially byone who is not thoroughly familiar with the joint. The distance A B, in Fig. 83, must not be less than thedistance A B in Fig. 84. 32 The Bridle Joint Boring Away Waste.—Examine Fig. 84; the shadedportion…
