the 14 lines and strike an arc. Dothe same from the other 14 line,Fig. 57. At the intersection ofthese arcs place one leg of the di-viders and draw the bottom curve,Fig. 58. On the other end do thesame. Place in a vise and plane tocurve, Fig. 59. Sandpaper the bot-tom, going across the grain, so…
