ed with aspoke shave, Fig. 117, and finishedby rubbing them with a strip ofsandpaper, in a manner similar tothat used in polishing a shoe with acloth, Fig. 118. Fit the wheel and axle to thehandles. This requires careful fit-ting. Put the box together withnails or screws. Nail the box tothe… … LESSON NO. 19HAT AND COAT RACK Carefully make a stock bill on form similar to one shownin Fig. 116. True pieces to correct sizes and shapes. Lay out the holes for the dowels. With marking gauge drawa center on the inner edge of each of the vertical pieces andalso on the ends of the horizontal…
