y trim the bottomof grooves with a sharp chisel, Fig.127. If the grooves are not quitewide enough or deep enough parecarefully with chisel to proper size,Fig. 128. Put together with glue andclamp. Allow twenty-four hours todry. Scrape off any surplus glue,and plane top and bottom surfacesflat.… … LESSON NO. 21A TABOURET The new problem involved in this project is to glue twoboards together to make a board wide enough for the top.Every other feature of the construction of a tabouret has beenworked out in some previous problem. Decide the particular kind of tabouret to be made. See…
