curs with zero rubbingvelocity and consequently there are no heating effects. CHAPTER VII STRESSES IN WORM GEARING In a subsequent chapter^ the stresses in the gears as affectedby the width of the wheel and the number of teeth in contactwill be investigated, but before considering these, it will… … Fig. 13. In the example already considered, the contact between theworm and the wheel is made at five different points simultane-ously, but owing to the fact that there are five threads to theworm, any diagrammatic representation of the same is muchcomplicated; let us, therefore, consider the same…
