Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools (1918)
Kissell, Mary Lois · New York, The Macmillian company · leaf 227
fected hand loom. I. frame including all working parts (29, 29e, h). Fig. 66. — Greek Loom of Middle Ages An early Perfected hand loom with all parts united within the frame. Itdiffers from the later form in its vertical warp and horizontal heddles. a. two cross-shape side boards joined above and… … Fig. 67.—Perfected Hand Loom with Fly-shuttle A rectangular frame supports all working parts. Horizontal warp, W, extendsbetween the revolving warp beam, A, and the cloth beam, B ; two treadles,T, raise and lower alternately the two shaft heddles, H, to open the warpsheds. The swinging batten, E,…
Textile industry · Spinning · Weaving
