Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools (1918)
Kissell, Mary Lois · New York, The Macmillian company · leaf 233
Reproduced by permisston from Hoopers Hand-loom Weaving.Macmillan, V. S. A., and John Hogg, London. Fig. 73.—-Shed Opening Mechanism. Treadles and Heddles at Work A, warp beam; B, cloth beam; C, lease rods; D, heddle harness pulley;E, treadles; F, shed opened by heddles and treadles. … Fig. 74. — Hand-shuttle at Work The shuttle is thrown from one hand to the other, leaving a line of weft throughthe open shed when the reed-batten will beat close the line of weft.
Textile industry · Spinning · Weaving
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
