Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools (1918)
Kissell, Mary Lois · New York, The Macmillian company · leaf 234
Fig. 74. — Hand-shuttle at Work The shuttle is thrown from one hand to the other, leaving a line of weft throughthe open shed when the reed-batten will beat close the line of weft. … Fig. 75. — Fly-shxjttle at Work With each jerk of the peg in the right hand the shuttle flies through the openshed to the shuttle box at the other end, leaving in its trail a line of weft.Then the left hand, freed from helping as required by the hand-shuttle, beatsup the weft with the reed-batten.…
Textile industry · Spinning · Weaving
