The young mechanic; containing directions for the use of all kinds of tools, and for the construction of steam engines and mechanical models, including the art of turning in wood and metal (1902)
[Lukin, James] [from old catalog] · New York, London, G. P. Putnam's sons · leaf 335
ill To£ of toiler Fig. 70. and will answer, even on a large scale, very satisfactorily.If you do not quite understand the action of these ports, cutout two pieces of card, E F. Let E represent the cylinder.Draw circles, and cut two ports. Cut another piece of card DETAILS. 321 to represent the…
Mechanical engineering · Industrial arts
