The young mechanic; containing directions for the use of all kinds of tools, and for the construction of steam engines and mechanical models, including the art of turning in wood and metal (1902)

[Lukin, James] [from old catalog] · New York, London, G. P. Putnam's sons · leaf 37

An illustration from The young mechanic; containing directions for the use of all kinds of tools, and for the construction of steam engines and mechanical models, including the art of turning in wood and metal, 1902, leaf 37
bore the two holes and nail it together; but be guardedas to splitting the pillars. You ought now to have the front well and firmly puttogether and standing square and true as in the sketch;only the bottom board, of which you see the front edge, isnot to be attended to at present. There is another… … Fig. 11. inserted at the top, and then being slightly bent are putin place in the bottom piece—each wire being completely ffOW TO MAKE A CAGE. n fixed bofore the next is added. Either way may be tried,but in that given above the wires are not bent at all, andtherefore have not to be straightened.…

Mechanical engineering · Industrial arts
