The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 150
arges into the atmos-phere,* the temperature readings (corrected) are ^i = 334.5 deg., (2 = 26L4 deg.What is the quality of the steam tested, assuming no radiation from the calo-rimeter? § 17 (i)) THROTTLING OR KINETIC PRESSURE LOWERING. 135 The pressure corresponding to 334.5 deg. is 109.5 lb.… … 40 P, 60 80 Lb. IOOAbs.120 140 160 180 ZOO 220Fig. 70. — Diagram for the Throttling Calorimeter. base is initial pressure pi, with which is laid out a variable scale ofcorresponding saturation temperature ^i. Curve AA shows, to thescale at the left, the temperature ^2 which results from the…
Steam-engines · Steam-turbines
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
