Bragg, William Henry, Sir, 1862-1942, Bragg, William Lawrence, Sir, 1890-1971 · London : G. Bell · leaf 38
g generally determined bypressing the face to be used against a metal templatewhich is afterwards removed. The reflected pencil of X-rays passes into anionisation chamber mounted so as to be capable ofrevolving about the same vertical axis as the crystaltable. An adjustable slit D stands in front… … X-RAV SPECTROMETER. LLL. Lead box. A, B. D, Slits. C, Crystal. /, lonisatioii chamber. V, \ernier oi crystal table. V , Nernier of ionisation chamber. K, Earthing key. E, Elect roscooe. M, Microscope. Facing /><igf 24. THE X-RAY SPECTROMETER 25 more effective than SOo. The chamber is insulatedfrom…
Crystallography · X-rays
Internet Archive Book Images · Gerstein - University of Toronto · No known copyright restrictions (public domain). Free to use for anything.
