Fox, William Paul. (from old catalog) · Chicago, Ill., Fox brothers · leaf 26
the holes, putting the boardin a vise, Fig. 45. Hold the braceand bit perpendicular to the sur-face of the board and bore untiltip of bit just comes through otherside of board. Then turn the boardaround and bore from the otherside. This will leave a clean cuthole from both sides, instead of aragged… … LESSON NO. 9 PIN TRAY Cut a piece of stock 7y2 long,6y2 wide, and % thick. With ripsaw cut this board into two pieces;one 7yo long by 3y2 wide, theother 7y2 long by 3 wide. Lay out with dividers and trysquare as shown in Fig. 49. Fig.50 is a photograph of the boardproperly laid out. Plane to the…
Woodwork · Mechanical drawing
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
