Natural philosophy. including statics, hydrostatics, pneumatics, dynamics, hydrodynamics, the general theory of undulations, the science of sound, the mechanical theory of music, etc. : designed for the use of normal and grammar schools, and the higher classes in common schools (1867)

Sangster, John Herbert, 1831-1904 · Montreal : Printed and published by John Lovell · leaf 155

An illustration from Natural philosophy. including statics, hydrostatics, pneumatics, dynamics, hydrodynamics, the general theory of undulations, the science of sound, the mechanical theory of music, etc. : designed for the use of normal and grammar schools, and the higher classes in common schools, 1867, leaf 155
Tr:XDEESHOT WHEEL. OVKESHOT WHEEL. XoTE. —The mode in which the water is made to act on these is repre-sented in Figs. 30, 31, 32. It will be observed that the undershot wheel ismoved by the momentum of the water—the breast wheel and overshotwheel by its weight aided by its momentum. An overshot…
