Merchant, F. W. (Francis Walter), 1855-1937, Chant, Clarence Augustus, 1865-1956 · Toronto : Copp Clark · leaf 466
t. The currents alternatelystrengthen and weaken the magnet of the receiver and thusset up vibrations in the diaphragmsimilar to those in the diaphragm ofthe transmitter. The Bell receiver is very sensitive andis still used on all telephone systems, buta magnet of the horse-shoe type is nowusually… … Fi«. 551.—The microphonetransmitter used in theHell system. 456 INDUCED CURRENTS At the back of the mouthpiece is a metallic diaphragmZ), _S is a carbon button attached to the diaphragm, and Banother carbon button attached to the frame of the instru-ment, opposite to B. The space between the carbon…
Physics
Internet Archive · Western University Libraries · Public Domain Mark 1.0. Free to use for anything.
