nnecting wires. A simple arrangementfor doing this is shown in Fig. 572. C isan induction coil, n, nbeing knobs on the endsof its secondary. A wireA runs up in the air fromone knob wdnle the otheris joined to earth. D is abattery and K a key inseries with the primary ofthe coil. On depressing KWm… … 486 OTHER FORMS OF RADIANT ENERGY At some distance away is the receiving apparatus. ^ is acoherer. From one pole of it a wire B runs up in the air;from the other pole a wire leads to earth. In circuit with thecoherer are a battery F and an electric bell G. The electricwaves travel from A with the…
