An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 1016

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 1016
the lobes of circu-lar windows, as also tiie way of obtaining the centres forthe lobes in a simple and symmetrical manner. In Jig,1192. the basis of formation is the equihiteral triangle,and three lobes are the result. Those of four lobes, orquatiefoils (_/?y. 1193.), originate from the square;… … Fig. 1196. 996 PRACTICE or ARCHITECTURE. Book III.
