An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 342

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 342
Fig. 470. Fig. 471. plane its projection ADBC is shown, being thereon represented by a circle, and upon vertical plane by the rectangle ffcdk. … FiK. 472.

Architecture · Architects

Internet Archive · University of Toronto Libraries · Public Domain Mark 1.0. Free to use for anything.
