An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 679

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 679
;however, in all their shapes, they are dependent onthe leading principles given. 2147. Fig. 760. is a ])lan of the shtitters, architrave,sasii-frame, and part of the sash of connnon shutters.The cavity which forms the boxing into which thesashes fold is formed by the ground B (upon whielitlie…
