An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)
Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 696
II. JOINERY. 675 will stand much better than wlien they are vertical. A is the plan of the base inverted,and B is the elevation. 2203. The formation of a modern Ionic capital is given in Jig. 798., wherein A is theplan inverted, showing the method of placing the blocks; and li is the elevation.… … 2205. Fig. 800. exhibits the mode of forming a cylindrical surface without veneers, bymeans of equidistant parallel grooves, A is the elevation, and B the plan. 2206. Fig. 801. exhibits the method of covering a conic body. It is, in fact, no morethan covering the frustum of a cone, and is…
