orrespondent point b of B in the section. From B draw in the direction of the light the line Bb b, cutting DD on the diameter in b ;w transfer the point b in the elevation to h in tlie section, and draw bb in the direction of the light indefinitely. Then with Bb as a radius from h as a centre,… … «30 TIIKOKY OF AUClllTECTUUE. lie II. wauld follow tlie description of the remaliuler of the operation, we have not encum-bered the diagram with more letters of reference; the lines showing, on inspection,similar applications of the process for all parts of the curve. The fact is, that the wholeof…
