An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 888

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 888
angular capital,something like the example of that in the temple ofFortuna Virilis. The height of his architrave, frieze,and cornice is a little less tiian a fifth part of thelieight of the cohnun, with its liase and capital. Tiietotal height of his order, in our measures, is 26 mo-dules. 2581. The… … 8()8 PRACTICE OF AIICIIITECTURE. Bo.K 1J[. Teos ; of Apollo DidymcTus at Miletus ; and of the small temple on the Ilyssus, nearAtlutis, whereof in Jiy. 887. the profile is given, and below, a table of the heights andprojections of the parts. It is to be observed, that in the Cirecian Ionic volute…
