An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 900

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 900
, as will beimmediately understood on refer-ence to Jiy. 894. ; wherein A is thesysytle monotriglyph intercolumnia-tion of ,3 modules ; B, that of the dia-style, or 6 modules; and C, the ar;co-style, or of 8 modules. The inter-columniation marked D serves for KiK. sgi. tiie application of coupled…
