An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 904

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 904
he whole void; a proportionwhicli, if we are to rely on the approval of ages in its application, will be found near thelimits of what is beautiful. 2620. We shall now refer to the examples of Vignola alluded to ; but to save the repe-tition of figures in their numbers, as referred to, each case is… … Fig. SS9. Fis- 100. 2621. Suppose the Tuscan example (Jiff. 899.) without an entablature, we have tlie Supports, 9-75 X 3 = 29-25 The whole of rectangle above them, 4-2.5 x 9-5 = 40-375 T • u C-5xG-5x 7854 , „ „Less semi-arch, „ = 16-6 23-775 53 025 solid parts. The area of the void is 16-6+ 9-75 x…
