An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 913

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 913
FiR. 912. Fig. 913. 2640. The example in fig. 912. is from the hand of Vignola, and was executed for one>f the Borghese family at Mondragone, near Frascati. In it the arch is a little moren height than twice its width, and the breadth of the pier columns supporting the arclincludes a little less…
